Guide: How to Print TIFF File in MicroStation – Step by Step

Welcome to our comprehensive guide on how to print a TIFF file in MicroStation. Whether you’re a beginner or an experienced user, this step-by-step tutorial will walk you through the process of printing a TIFF file with ease. So let’s dive in and learn how to achieve high-quality prints using MicroStation’s powerful printing capabilities.

how to print tiff file in microstation

Key Takeaways:

  • Printing a TIFF file in MicroStation is a straightforward process.
  • Open the Print dialog box by selecting Print from the File menu or pressing CTRL+P.
  • Select the print area mode, such as sheet definition, fence, or view, according to your requirements.
  • Choose a printer from the available options in the Print dialog box.
  • Adjust printing parameters, including sheet size, scale, and orientation to customize your print.

Opening the Print Dialog Box in MicroStation

To print a TIFF file in MicroStation, you first need to open the Print dialog box. There are two ways to access this dialog box: by selecting “Print” from the File menu or by using the keyboard shortcut CTRL+P. Opening the Print dialog box allows you to adjust the various printing parameters and settings in MicroStation.

Once the Print dialog box is open, you’ll see a menu bar at the top and an icon bar below it. These bars provide access to different printing functions and settings. The menu bar contains options for selecting the print area, printer, and paper size, while the icon bar provides shortcuts to commonly used printing tools and actions.

By opening the Print dialog box, you gain control over the printing process in MicroStation. It is the gateway to customizing the print settings, previewing the print layout, and initiating the printing process. The intuitive layout and options in the Print dialog box make it easy to navigate and adjust the printing parameters according to your specific requirements.

Overall, the Print dialog box in MicroStation is a powerful tool that allows you to fine-tune the printing of TIFF files. Whether you’re working on architectural drawings, engineering designs, or any other project, mastering the Print dialog box will ensure that your prints are accurate, professional, and meet your exact specifications.

Selecting the Print Area and Printer in MicroStation

In MicroStation, when you are ready to print your design, you have the flexibility to choose the print area and the printer that best suits your needs. This section will guide you through the process of selecting the print area and printer in MicroStation.

Print Area

MicroStation offers different print area modes, including sheet definition, fence, and view. These modes allow you to specify the portion of your design that will be printed. The “Sheet Definition” mode enables you to print the entire sheet or a defined area within it. The “Fence” mode lets you print a specific shape or area defined by a fence element. Lastly, the “View” mode allows you to print the current view on your screen. By choosing the appropriate print area mode, you can ensure that only the desired portion of your design is printed.

Printer Selection

MicroStation provides a range of printer options to meet your printing requirements. In the Print dialog box, you can select a printer from the available options. Each printer may have specific features or capabilities that can be leveraged through MicroStation. Whether you need high-quality prints or specific print settings, MicroStation gives you the flexibility to choose the printer that best suits your needs. Selecting the right printer is crucial for achieving the desired print output.

Now that you understand how to select the print area and printer in MicroStation, let’s move on to the next section to learn about adjusting the printing parameters for optimal print results.

Adjusting Printing Parameters in MicroStation

The Print dialog box in MicroStation offers a range of options for customizing your printing parameters. By adjusting these settings, you can ensure that your printed output meets your specific requirements. Here are some of the key parameters that you can modify:

Sheet Size and Scale

One important aspect of printing in MicroStation is selecting the appropriate sheet size and scale. In the Print dialog box, you can choose from a variety of standard sheet sizes or even define a custom size. Additionally, you can adjust the scale of the print to match the desired level of detail. MicroStation provides the flexibility to set the scale manually or use the Scale Assistant dialog box for more precise control.

Print Size and Position

To ensure that your print fits perfectly on the selected sheet, you can adjust the print size and position in MicroStation. Within the Print dialog box, you have the option to expand the dialog box to visually check the printed output. This allows you to verify the layout and make any necessary adjustments before printing. You can also set the print position on the sheet to achieve optimal placement.

Grayscale and Monochrome Printing

MicroStation provides the ability to print in grayscale or monochrome, in addition to color. This allows you to choose the printing mode that best suits your needs. Whether you want to preserve intricate details in color or simplify the print for better clarity, MicroStation gives you the flexibility to customize the output to your preference. The Print dialog box offers options for selecting the desired printing mode and adjusting the settings accordingly.

microstation print settings

Parameter Description
Sheet Size and Scale Choose the appropriate sheet size and adjust the scale of the print.
Print Size and Position Adjust the size and position of the print on the selected sheet.
Grayscale and Monochrome Printing Select the desired printing mode, whether it is color, grayscale, or monochrome.

Selecting Printer Driver in MicroStation

When it comes to printing in MicroStation, selecting the right printer driver is crucial. MicroStation offers two types of printer drivers: Windows Printer and Bentley Driver. Each driver has its own set of features and capabilities, allowing you to optimize your printing experience based on your specific needs.

To select the printer driver in MicroStation, you can go to the Print dialog box and choose either Windows Printer or Bentley Driver. By selecting Windows Printer, the default Windows printer driver file is loaded, providing you with a wide range of compatibility options. On the other hand, selecting Bentley Driver loads the last used Bentley printer driver file by default, giving you access to Bentley-specific features and optimizations.

It is worth noting that you can also define a default printer driver file using the configuration variable MS_PLOTDLG_DEF_PLTFILE. This allows you to have a preferred printer driver loaded automatically every time you open the Print dialog box in MicroStation. By choosing the appropriate printer driver, you can ensure that your prints are of the highest quality and aligned with your desired specifications.

Printer Driver Comparison

Printer Driver Features Capabilities
Windows Printer Wide compatibility Supports various file formats
Bentley Driver Bentley-specific optimizations Enhanced print quality

By comparing the features and capabilities of the Windows Printer and Bentley Driver, you can make an informed decision when selecting the appropriate printer driver in MicroStation. Consider factors such as file format compatibility, optimization options, and print quality to ensure that you achieve your desired printing results.

Printer Languages and Supported Formats in MicroStation

MicroStation’s printing system supports a variety of printer languages and formats, providing flexibility and compatibility for your printing needs. The available printer driver files in MicroStation allow you to generate output in industry-recognized formats such as HPGL/2, HPGL/RTL, ESC/P, TIF, CGM, and PostScript, among others.

microstation printer drivers

When printing in MicroStation, it is essential to select the appropriate printer driver file that corresponds to the desired format. The printer driver file determines the capabilities and features available for your printing tasks. Choosing the right printer driver ensures accurate and high-quality output.

To select the printer language and format, you can refer to the Print dialog box in MicroStation. This dialog box allows you to choose the desired printer driver file, which ultimately determines the output format of your printed documents. MicroStation also provides generic templates for commonly used printer languages, making it easier to select the appropriate format for your printing requirements.

Setting Paper Size, Scale, and Orientation in MicroStation

In the Printer and Paper Size section of the Print dialog box, you have the flexibility to specify the paper size and orientation for your print in MicroStation. The wide range of pre-defined paper sizes available in MicroStation ensures that you can choose the most suitable option for your printing needs. Additionally, you have the ability to edit the dimensions of the selected paper size to further customize it based on your specific requirements.

Having control over the scale of your print is essential to ensure accurate representation of your design. In MicroStation, you can easily set the scale for your print in the Scale field of the Print dialog box. You have two options for setting the scale: you can either enter a specific value or use the Scale Assistant dialog box. The Scale Assistant provides a user-friendly interface where you can define the scale criteria based on design to paper or paper to design measurements.

Orientation is another important aspect of printing that you can adjust in MicroStation. In the Print dialog box, you can choose between portrait and landscape orientations to best suit the layout of your design. By selecting the appropriate orientation, you can ensure that your printed output accurately represents your intended design.

Table: Available Paper Sizes in MicroStation

Paper Size Dimensions
Letter 8.5″ x 11″
Legal 8.5″ x 14″
Tabloid 11″ x 17″
A4 210mm x 297mm
A3 297mm x 420mm

By understanding how to set the paper size, scale, and orientation in MicroStation, you can ensure that your printed output meets your exact specifications. Whether you need to print a design on a specific paper size, adjust the scale for accurate representation, or choose the orientation that best suits your layout, MicroStation provides the necessary tools for precise and customizable printing.


Printing TIFF files in MicroStation is a seamless process that allows you to achieve the desired layout and quality. By following the step-by-step guide provided, you can easily print your TIFF files with precision and efficiency.

MicroStation offers a comprehensive range of options and settings to customize your prints. You have the flexibility to select the print area, adjust printing parameters, choose a printer, and even preview your print before initiating the process. This ensures that you have complete control over the final output.

Key features such as paper size, scale, orientation, and printer driver selection can be easily customized to meet your specific requirements. Whether you need to print in grayscale or monochrome, MicroStation provides the necessary tools to achieve your desired result.

By mastering the printing capabilities of MicroStation, you can confidently print your TIFF files in a professional manner, ensuring the highest quality and accuracy. Take advantage of the powerful features and customization options available, and elevate your printing experience with MicroStation.
